Overview Specs

• 39.37 (X-Axis) x 26 (Y-Axis) x 24.01 (Z-Axis) in (1,000 x 660 x 610 mm) travels
• 945 x 945 x 787 in/min (24 x 24 x 20 m/min) X, Y, and Z rapids
• 4 box ways supporting y-axis
• 24-station swing-arm ATC
• 12,000 RPM belt-driven spindle
• 40 taper
• 41.34 x 25.59 in (1,050 x 650 mm) table, 2,204.62 lbs (1,000 kg) capacity
• 14,770 lbs (6,700 kg) machine weight

Full Product Specifications

Overview Specs

• 43.31 (X-Axis) x 26 (Y-Axis) x 24.01 (Z-Axis) in (1,100 x 660 x 610 mm) travels
• 945 x 945 x 787 in/min (24 x 24 x 20 m/min) X, Y, and Z rapids
• 4 box ways supporting y-axis
• 24-station swing-arm ATC
• 6,000 RPM 2-speed gear-type spindle
• 50 taper
• 45.28 x 25.59 in (1,150 x 650 mm) table, 2,420 lbs (1,097.6 kg) capacity
• 14,960 lbs (6,785.74 kg) machine weight

Full Product Specifications

Overview Specs

• 60 (X-Axis) x 30 (Y-Axis) x 28.35 (Z-Axis) in (1,524 x 762 x 720 mm) travels
• 708 x 708 x 630 in/min (18 x 18 x 16 m/min) X, Y, and Z rapids
• 4 box ways supporting y-axis
• 24-station swing-arm ATC
• 6,000 RPM 2-speed gear-type spindle
• 50 taper
• Pre-tensioned ball screws minimize thermal deformation
• 62.99 x 29.92 in (1,600 x 760 mm) table, 3,300 lbs (1,496.85 kg) capacity
• 30,865 lbs (14,000 kg) machine weight

Full Product Specifications
